- Rate : 1.25Gbps/1.063Gbps
- Transmission distance : 20kms
- Channel : Simplex
- 1310/1550nm DFB laser and PIN receiver
- The transceiver consists of three sections: a DFB laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit.
- All modules satisfy class I laser safety requirements.
- Specification
- Downloads
| MODEL NO | AEXS-BI5312-20D |
|---|---|
| FORM FACTOR | SFP |
| MEDIA | Single Mode Fiber |
| CONNECTOR | LC/SC |
| AMBIENT OPERATING TEMPERATURE | 0~+70°C |
| MAX DATA RATE | 1.25Gbps |
| MAX CABLE DISTANCE | 20kms on SMP |
| POWER SUPPLY | +3.3V power supply |
| STANDARD | IEEE Std 802.3. |
